2017+ Can-Am X3 Stage-4 Audio System (Gen-3) X317-STG4
2017+ Can-Am X3 Stage-4 Audio System (Gen-3) X317-STG4
The easiest SXS kits to install and set up, optional Color Optix™ lighting control, and even higher performance, all to ensure an epic off-road audio experience.
Features & Benefits:
Plug-and-Play Design: No drilling, no cutting and designed to work right out of the box. Simple installation ensures less time in the garage and more time out riding.
Element Ready™: Purpose built for the off-road environment, Rockford’s Element ReadyTM products are built to stand up to water, dirt, mud and UV rays, making sure all your audio components perform regardless of the conditions.
RF3 (Rockford Factory Fit & Finish): Designed and engineered to match and compliment the factory fit and finish of your vehicle. These components are purpose built to the exact specifications to ensure the best in class fitment and look.
Connectivity Control: With Bluetooth connectivity, AUX and USB inputs, it’s easy to control your music or even charge your phone, no matter where the trail takes you.
Compatibility Chart: Please review below tab for fitment before purchasing.
New Audio Kits
Can-Am X3 Product Overview
Color Optix™ Controller
X317-STG4 Install Tutorial
STAGE-4 PERFORMANCE
Our Gen-3 Stage 4 lets you hit the dunes and trails and make an impact! System allows you to add front and rear Color Optix™ speakers and a subwoofer on select Maverick X3 models. Kit is equipped with a PMX-2 digital media receiver, upper dash kit, front speaker panels, M1 6.5” Color Optix™ speakers, 800-watt Element Ready™ amplifier, under-seat front subwoofer enclosure, M1 10” Element Ready™ subwoofer, 8-gauge wiring harness, M1 6.5” Color Optix™ moto-cans with harness, and a Color Optix™ controller. Kit supplied with all necessary mounting and installation hardware requiring minimal time and tools. Refer to our COMPATIBILITY chart to verify fitment before purchasing.
Download RF Connect™ to control the PMX-RGB:
FEATURES AT A GLANCE
- Color Optix™ enabled
- Complete Element Ready™ audio system
- Direct connect wiring harnesses for Can-Am X3 models
- PMX-2: Compact AM/FM/WB Digital Media Receiver 2.7" Display
- Enclosures for speakers and/or subwoofer integrate with no loss of passenger space
- Easy setup of audio system: amplifier preset for maximum performance without tuning
- X317-DK: Dash Kit for PMX-1, PMX-2 or PMX-3 on Select Can-Am® Maverick X3 Models
- X317-FSE: 6.5" Front Color Optix™ Speaker Panels with Smart-Lok for Select Can-Am® Maverick X3 Models
- M1-65B: M1 6.5” Color Optix™ Marine 2-Way Speakers - Black
- M5-800X4: 800-watt 4-channel IPX6 Element Ready™ amplifier
- X317-M1FWE: M1 10" Element Ready™ Loaded Subwoofer Enclosure for Select Can-Am® Maverick X3 Models (no RGB Color Optix™)
- X317-K8: 8 AWG Amp Installation Kit for Select Can-Am® Maverick X3 Models
- M1WL-65MB: M1 6.5" Element Ready™ Color Optix™ Moto-Can Speaker - Black
- MX-RSW16: Rear Color Optix™ Speaker Add-On Harness for Select UTV Models
- PMX-RGB: Color Optix™ Light Controller with Optional App Interface
- Includes wired antenna
New Audio Kits
Epic Elevated Performance! Introducing all new audio kits for select Polaris® RZR® and Can-Am® X3 models.
Can-Am X3 Product Overview
Check out the all new Rockford Fosgate Color Optix™ Audio Kits for select Can-Am® MAVERICK X3 models. This product overview will help you understand the difference between each stage kit. Which kit is the best fit for you?!
Color Optix™ Controller
The PMX-RGB Color Optix™ controller provides LED lighting control for your Can-Am Color Optix™ audio system. Pair this with our RF Connect™ smartphone app and give your system infinite control by customizing the color and lighting effects of your speakers.
X317-STG4 Install Tutorial
The 3rd generation installation tutorial on the Rockford Fosgate X317-STG4 motorsport audio installation kit for select 2017+ Can-Am® MAVERICK X3 models. For kit details and compatibility, please see below details.
All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.
Learn more
Element Ready™ | Motorsports
All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.
Water projected in powerful jets from any direction shall have no harmful effects.
Learn more
IPX6 Water Intrusion Rating
Water projected in powerful jets from any direction shall have no harmful effects.
Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play ...
Learn more
Color Optix™ Control
Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play controller and App (sold separately.)
(1 ea) X317-DK
(1 pr) X317-FSE
(1 pr) M1-65B
(1 ea) M5-800X4
(1 ea) X317-M1FWE
(1 ea) X317-K8
(1 pr) M1WL-65MB
(1 ea) MX-RSW16
(1 ea) PMX-RGB
YES
Can-Am model IS compatible with kit |
NO
Can-Am model NOT compatible with kit |
NOT AVAILABLE
Can-Am model not produced this year |
|---|
YES
 2-Seat |
YES
 4-Seat |
YES
 Hi/Low Seat Level |
COMPATIBLE
 Front Window (remove to install speakers) |
POSSIBLE
 Rear Window (mount cans externally) |
POSSIBLE
 Snorkel (mount cans externally) |
|---|
| MODEL |
 2017 |
2018 |
2019 |
2020 |
2021 |
2022 |
|---|---|---|---|---|---|---|
| X3 900 HO [64] | — | ✔ | — | — | — | — |
| X3 Turbo [64] | — | ✔ | ✔ | ✔ | — | — |
| X3 Turbo R [64] | ✔ | ✔ | ✔ | — | — | — |
| X3 ds Turbo [64] | — | — | — | — | ✔ | ✔ |
| X3 ds Turbo R [64] | — | — | — | ✔ | ✔ | — |
| X3 ds Turbo RR 64 | — | — | — | — | — | ✔ |
| X3 rs Turbo R [72] | — | — | — | ✔ | — | — |
| X3 rs Turbo RR 72 | — | — | — | — | — | ✔ |
| X3 X ds Turbo R [64] | ✔ | ✔ | ✔ | — | — | — |
| X3 X ds Turbo RR [64] | — | — | — | ✔ | ✔ | ✔ |
| X3 X mr Turbo [64] ¹ | — | ✔¹ ³ | ✔¹ ³ | ✔¹ | ✔¹ | — |
| X3 X mr Turbo R [72] ¹ | — | ✔¹ ³ | ✔¹ ³ | — | — | — |
| X3 X mr Turbo RR 64 | — | — | — | — | — | ✔ |
| X3 X mr Turbo RR [72] | — | — | — | — | ✔ | ✔ |
| X3 X mr Turbo RR [72] ¹ | — | — | — | ✔¹ | ✔¹ | — |
| X3 X rc Turbo [64] | — | ✔ | ✔³ | ✔ | ✔ | — |
| X3 X rc Turbo R [72] ² | — | X² | X² | — | — | — |
| X3 X rc Turbo RR 64 | — | — | — | — | — | ✔ |
| X3 X rc Turbo RR [72] ² | — | — | — | X² | X² | X² |
| X3 X rs Turbo R [72] | ✔ | ✔ | ✔³ | — | — | — |
| X3 X rs Turbo RR [72] | — | — | — | ✔ | — | ✔ |
| X3 X rs Turbo RR Smart-Shox [72] | — | — | — | — | ✔ | ✔ |
| MODEL |
2017 |
2018 |
2019 |
2020 |
2021 |
2022 |
|---|---|---|---|---|---|---|
| Maverick X3 MAX Turbo [64] | — | ✔ | ✔ | ✔ | — | — |
| Maverick X3 MAX Turbo R [64] | ✔ | ✔ | ✔ | — | — | — |
| Maverick X3 MAX ds Turbo [64] | — | — | — | — | ✔ | ✔ |
| Maverick X3 MAX ds Turbo R [64] | — | — | — | ✔ | ✔ | — |
| Maverick X3 MAX ds Turbo RR 64 | — | — | — | — | — | ✔ |
| Maverick X3 MAX rs Turbo R [72] | — | — | — | ✔ | ✔ | — |
| Maverick X3 MAX rs Tubro RR 72 | — | — | — | — | — | ✔ |
| Maverick X3 MAX X ds Turbo R [64] | ✔ | ✔ | ✔³ | — | — | — |
| Maverick X3 MAX X ds Turbo RR [64] | — | — | — | ✔ | ✔ | ✔ |
| Maverick X3 MAX X mr Turbo RR [72] ¹ | — | — | — | ✔¹ | ✔¹ | ✔¹ |
| Maverick X3 MAX X rs Turbo R [72] | ✔ | ✔ | ✔³ | — | — | — |
| Maverick X3 MAX X rs Turbo RR [72] | — | — | — | ✔ | ✔ | ✔ |
| Maverick X3 MAX X rs Turbo RR Smart-Shox [72] | — | — | — | — | ✔ | ✔ |
Charts contain newer naming convention — started in 2022 — featuring 64" and 72" width models. Older models denote [width] in name to clarify make/model/year progression.
1
Snorkel prevents stages with rear moto-cans from being installed inside roll-cage, must be installed outside roll-cage.
2
Intrusion Bar introduced in 2018, causes (FSE) front speaker clearance issue.
3
Smart-Lok™ introduced in 2018, requires 2nd (RFX317-FSE) or 3rd generation (X317-FSE) front speaker panels.
Return Authorization
Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.
